Menics MS86L-F02-B 86mm Beacon Light, 24V, Blue

Description

The Menics MS86L-F02-B 86mm beacon light is 24V AC/DC with a blue lens and a steady or flashing LED light. The prism cut lens provides a wide light distribution. An inside jumper is used to select steady or flashing mode. Useful for industrial machinery, it is made to be seen from a distance and will not generate much heat, even when in use for extended periods. Rated IP 65. Note: See the link to our accessory chart below the description to find out which mounting accessories are compatible with each other.

Specifications

• Mounting- Stud Mount (see mounting accessories below – MAM-DS31 adapter must be used if pole mounting)
• Light Type- LED Steady/Flashing
• Power Supply- 24V AC/DC
• Lens Color- Blue
• Lens Material- Polycarbonate Resin
• Dimensions- 112 mm Height x 86 mm Diameter (4.4″ x 3.4″)
• Current Consumption- 0.46 Amps
• Brightness- 15 Lumens (1190 mcd)
• Flash Rate- 80 times per minute
• Buzzer- None (see below for version with buzzer alarm)
• Vibration- 0.75mm @ 10-55Hz
• Insulation Resistance- 100 MOhm min. (500VDC mega)
• Ambient Temperature- -20 C to 40 C (-4 F to 104 F)
• Storage Temperature- -20 C to 70 C (-4 F to 158 F)
• Ambient Humidity- 45-85% Relative Humidity
• Recommended Wire Size- PUR ∅5/PVC ∅1.25 2P 0.3SQ, 300mm
• IP Protection- IP 65 (Total protection from dust and water jets in any direction)
• Approvals- RoHS, UL

Find out which mounting accessories you need with our Menics Signal Light Mounting Accessory Chart
